Servo MSMD5AZS1S Panasonic
| Item |
Specifications |
| Part Number |
MSMD5AZS1S |
| Details |
Low inertia, Lead wire type, IP65 |
| Family Name |
MINAS A5 |
| Series |
MSMD Series |
| Type |
Low inertia |
| Protection class |
IP65 |
| About Enclosure |
Except rotating portion of output shaft and leadwire end. |
| Environmental Conditions |
For more details, please refer to the instruction manual. |
| Flange sq. dimension |
38 mm sq. |
| Flange sq. dimension (Unit:mm) |
38 |
| Motor lead-out configuration |
Lead wire |
| Motor encoder connector |
Lead wire |
| Power supply capacity (kVA) |
AC100 V : 0.4 kVA
AC200 V : 0.5 kVA |
| Rated output (W) |
50 |
| Rated current (A (rms)) |
1.1 |
| Holding brake |
without |
| Mass (kg) |
0.32 |
| Oil seal |
without |
| Shaft |
Key-way, center tap |
| Rated torque (N ⋅ m) |
0.16 |
| Momentary Max. peak torque (N ⋅ m) |
0.48 |
| Max. current (A (o-p)) |
4.7 |
| Regenerative brake frequency (times/min) |
Without option :No limit
With option :No limit
Option (External regenerative resistor) Part No. : DV0P4280 (For AC100 V) , DV0P4281 (For AC200 V) |
| About regenerative brake frequency |
Please refer to the details of [Motor Specification Description] , Note: 1, and 2. |
| Rated rotational speed (r/min) |
3000 |
| Rated rotational Max. speed (r/min) |
5000 |
| Moment of inertia of rotor ( x10-4 kg ⋅ m²) |
0.025 |
| Recommended moment of inertia ratio of the load and the rotor |
30 times or less |
| About recommended moment of inertia ratio of the load and the rotor |
Please refer to the details of [Motor Specification Description] ,Note: 3. |
| Rotary encoder: specifications |
17-bit Absolute/Incremental system |
| Notice |
When using a rotary encoder as an incremental system (not using multi-turn data), do not connect a battery for absolute encoder. |
| Rotary encoder: Resolution |
131072 |
