XTOP08TV-ED-E M2I Màn hình cảm ứng
XTOP08TV-ED-E
XTOP08TV-ED-E
XTOP08TV-ED-E M2I
XTOP08TV-ED-E MÀN HÌNH ĐỒ HỌA 8″ XTOP
1. Bộ xứ lý tính năng cao cấp, 32bit RISC (ARM) Processor, tốc độ cao 400MHz, hoạt động tin cậy.
2. bộ nhớ khổng lồ 26MB Screen Memory, 256KB Back Up Memory
3. Độ nét cao Mono (Blue) LCD
4. Khác nhau Tích hợp giao diện Ethernet, CF Card, USB Host / Device.Serial
| Display |
Display Type |
8,4″ TFT Color |
| Number of colors |
65,536 Color |
| Dimension display (mm) |
170,9×128,2 |
| Resolution |
640×480 |
| Levels of brightness |
8 levels (software) |
| Backlight Type |
LED |
| Backlight Viability |
50,000 hours |
| Fonts |
6×6/8×8/12×12/8×16/16×16/32×32 points, Possible MS Windows font |
| Touch |
Touch type |
Analog resistive foil |
| Resolution |
640×480 |
| Viability |
minimum of 1 million touches |
| Interfaces |
serial
COM1 |
- RS-232C Asynchronous
- Data bits: 7/8, Stop Bit: 1/2, Parity: No / Odd / Even
- Speed: 2400bps do 115.2kbps
- Socket: PS2 6-pin or 9-pin DSUB 1 Channel
|
Serial
COM2 |
- RS-232C, RS-422/485 Asynchronous
- Data bits: 7/8, Stop Bit: 1/2, Parity: No / Odd / Even
- Speed 2400bps do 115.2kbps, 187.5kbps(MPI Directly)
- Connector: 9-pin DSUB 1 Channel
|
| Ethernet |
- IEEE802.3i/IEEE802.3u, 10BASE-T/100BASE-TX
- Socket: RJ-45 1 Channel
|
| Module options |
─ |
| USB Device |
V1.1 Compatible 1 Channel, Max 5m |
| USB Host |
- Output 5V / 0.5A USB V1.0 compatible (FAT16 / FAT32)
- USB barcode reader / USB scanner (standard protocol for the keyboard)
|
| Card CF |
Card CF(Typ-II) 1 Socket
Compatible (FAT16/FAT32) |
| Printer |
Roll Printer (EPSON protocol): RS-232C port COM1 |
Memory and
other |
Program memory |
26MB |
| Latching |
- 512KB: Buffer System (5K words), Including Alarms / logs / Recipes
|
| Backup time |
5 years (battery and the ambient temp. 25 ° C) |
| Battery |
- Lithium Battery: Charging time 1 day,
30 days to maintain the state of the program
- Lithium Battery: Secondary (removable), 2 years to maintain the state of the program
|
| Clock RTC |
Built-in |
| LED Status |
Built-in |
General
| Power supply |
voltage power supply |
DC24V(20~28V) |
| Power consumption |
15W or less |
| Accepted voltage decays |
24V, for 10 ms |
| Insulation resistance |
500V DC, 10MΩ |
| Environment |
Operating temperature (°C) |
-10 ~ +50 |
Temperature
of storage (°C) |
-20 ~ +60 |
Permitted residual
moisture (%RH) |
0 ~ 90 (non-condensing) |
| atmosphere |
corrosive environment |
| Vibration resistance |
Amplitude: 10≤F<25Hz(2G)
X, Y, Z in each direction (for 30 minutes) |
| Shock resistance |
10G X, Y, Z in each direction (3 times) |
| Overvoltage resistance |
500V(Interfacial) |
| Ground connection |
Class 3 (below 100Ω) |
| Protection class |
IP65 |
| Construction |
Excision of the panel(mm) |
222×168 |
| The external dimension(mm) |
233x178x60 |
| Weight(kg) |
1,3 |
| Cooling |
Natural circulation |
| Housing |
ABS(self-extinguishing) |
